Hanna Multiparameter pH, TDS, EC, Temperature Meter, HI9811-51
Price :
৳36500
Estimated Shipping Time: Deliveries take up to 2-3 days after you place your order.
Uses: Lab Essentials
Product SKU: 8RU12561W9
Hanna Multiparameter pH, TDS, EC, Temperature Meter, HI9811-51
These meters feature a large LCD that displays Multiparameter pH, EC, TDS, or temperature readings along with tutorial instructions. The pH readings are shown with a 0.1 resolution and an accuracy of ±0.1 pH while the EC and TDS readings are displayed with a 10 m/s/cm and 10 ppm (mg/L) resolution and 2% full-scale accuracy. Please select the meter with the range you require for your testing.
The temperature correction coefficient (β) is fixed at 2%/°C and allows for automatic temperature-compensated measurements of EC and TDS. These meters are calibrated manually to a single point with the use of two trimmers. pH is calibrated to 7.01, while EC/TDS is calibrated to 1.41 mS/cm (1413 µS/cm) or 1500 PPM. The LCD screen has a battery life indicator as well as on-screen tutorial messages.
No probe changes are required when switching your measured parameter between pH, conductivity, and TDS. These multiparameter meters reduce the number of instruments required for daily water quality analysis.
The supplied probe on all models features a polypropylene body, an amplified pH electrode with a built-in EC/TDS, and temperature sensors. The amplifier for the pH electrode prevents interference from humidity and electrical noise from common sources including the motors, ballasts, or pumps.
Specification of HI9811-51 Multiparameter pH, TDS, EC, and
Tem. Meter :
|
Range |
EC |
0 to 6000 µS/cm |
|
TDS |
0
to 3000 ppm (mg/L) |
|
|
pH |
0.0 to
14.0 pH |
|
|
Temp |
0.0
to 70.0°C |
|
|
Resolution |
pH |
0.1 pH |
|
EC |
10
µs/cm |
|
|
TDS |
10 ppm
(mg/L) |
|
|
Accuracy (@20°C/68°F) |
pH |
±0.1
pH |
|
EC |
±2% F.S. |
|
|
TDS |
±2%
F.S. |
|
|
Temp |
±1°C |
|
|
TDS Conversion Factor |
0.5
ppm (mg/L) = 1 µS/cm |
|
|
pH Calibration |
manual, 1
point through offset trimmer |
|
|
EC/TDS Calibration |
manual,
1 point through slope trimmer |
|
|
EC/TDS Temperature Compensation |
automatic
from 0 to 70°C with β = 2% /°C |
|
|
Probe |
HI
1285-51 pH/EC/TDS/Temperature, polypropylene body, pre-amplified
multiparameter probe with internal temperature sensor, 8-pin DIN connector,
and 1m cable included |
|
|
Battery Type / Life |
9V /
approximately 450 hours of continuous use |
|
|
Environment |
0
to 50°C; RH 100% |
|
|
Dimensions / Weight |
145 x 80
x 36mm / 230g |
|
|
Ordering Information |
HI-9811-51
and HI-9812-51 are supplied with HI-1285-51 multiparameter probe, HI-70007 pH
7.01 calibration solution sachet, HI-70032 1382 ppm (mg/L) calibration
solution sachet, HI-70031 1413 µS/cm calibration solution sachet, HI-700661
electrode cleaning solution sachets x 2, 9v battery x 1, instructions and
rugged carrying case. |
|
|
Accessories |
HI-710007
blue shockproof rubber boot; HI-710008 orange shockproof rubber boot |
If you'd like to know more about this chemical or need any analysis report regarding this chemical then contact us: support@echem.com.bd.
Hanna Multiparameter pH, TDS, EC, Temperature Meter, HI9811-51
HI-1285-51 Probes
The HI-9811-51 and HI-9812-51 are supplied with the HI-1285-51 pH/EC/TDS/temperature probe. The pH, EC, TDS, and temperature sensor are housed in a single body that connects to the meter with a DIN connector.
Amplified pH electrode
The pH electrode circuit has a built in amplifier that will reduce the effects of electrical noise on the high impedance pH measurement. Examples of sources of electrical noise include motors, ballasts, and pumps which are common in greenhouses.
Amperometric EC/TDS sensor
The EC/TDS readings are performed by an amperometric sensor. An alternating voltage is applied to the sensor and the amount of current that passes between the two stainless steel pins is dependent upon the amount of salts (fertiliser) present. A greater amount of salt present results in an increase in conductance.
Polypropylene body
The polypropylene body houses all the sensors in a single body design and is durable. The probe is gel filled for maintenance free operation. It does not have to be refilled periodically.
3 sensors in a single probe
Gel filled maintenance free pH electrode
